Electrical Characteristics
Specifications
·Circuit: 1P2T
·Rating: 0.5A 50VDC
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 500VAC at 10mA for 5 seconds (terminal-terminal); 3000VAC at 10mA for 5 seconds (terminal-knob)
·Environment temperature: -25°C to +85°C
·Operating force: 1.2-2.5N
·Life cycle: 10,000 cycles
