Electrical Characteristics
Specifications
·Working rating: 24VDC 26mA
.LED (power on): red
.LED (proximity): blue
.Proximity range: 3~15cm
.Adjustable opening time: 0.5~20Sec./latched on or off
.Relay contact rating: 125VAC 0.5A, 30VDC 1A
·Electrical life: Min. 100,000 operations at 1200 operations/hr
·Mechanical life: Min. 10,000,000 operations at 1800 operations/hr
.Protection degree: IP65
Materials
·Shell: Brass
·Case: UV & fire polycarbonate
