Car power USB charger USB A & C type socket with LED backlight & dust-proof cover
Input: 12V / 24V
Output: 5V 2.4A
Dieses Produkt ist derzeit online nicht verfügbar,Bitte senden Sie uns Ihre Anfrage!
Datenblatt
Elektrische Eigenschaften

Overview

Auto USB Charger – Fast Car Charger with Multi-Port USB-A/USB-C Output
Charge your devices on the road with this auto USB charger. Compatible with cars, trucks, and RVs, it offers universal support for iPhone, Android, tablets, and GPS devices. Featuring dual-port and multi-port options, fast charging protocols, and built-in safety protections, it ensures reliable power delivery while traveling. Compact and portable design makes it perfect for commuters and road trips.

Features

.Snap-in dual USB charger with dust-proof cover
.Reverse polarity protection
·Short circuit protection
·Over-load protection
·Over current protection
·Over temperature protection
·Over voltage protection
.Under voltage protection
.Backlighting power indication

Specifications

·Output connector: USB A & C socket
·Input voltage: 12V / 24V DC
·USB output
Type A: 5VDC 2.4A Max./1port
Type C: 5VDC 3A Max./1port
·Faston terminals: 6.3mm
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 1500VAC for 1 minute
·Operating temperature: -30°C to +45°C

Materials

·Housing: Nylon 66 (UL94V-2)
·Top contact: PC
·Cap: PVC
