Features
·Sealed
·Through hole type
Specifications
·Rating: 50mA 24VDC
·Contact resistance: 100mΩ Max.
·Insulation resistance: 100MΩ Min. at 250VDC
·Dielectric strength: 250VAC for 1 minute
·Operation force: 160±50gf
·Travel: 0.35±0.15mm
·Operation temperature: -40°C to +80°C
·Storage temperature: -40°C to +85°C
·Protective grade: IP67
·Electrical life: 1,000,000 cycles Min.
Applications
·Audio
·OA equipment
·Instrumentation
·Communication
·White goods
