電気の特性
Specifications
·Gender: Male
·Rating: 10A 250VAC / 15A 250VAC
·Mounting: Panel mount
·Body orientation: Straight
·Termination: Quick connect
·Faston terminals: 4.8 x 0.8mm
·Contact resistance: 30mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 3000VAC for 1 minute
·Inserting force: 10N-50N
·Extracting force: 10N-50N
·Ambient temperature: 10°C to 25°C
·Relative humidity: 45% to 85%
·Life: 6,000 cycles
Materials
·Body: PA66 UL94V-2
·Pins: Cu, Sn plated
