Specifications

·Gender: Female
·USB connector type: Dual C
·Current rating: 5A for power supply
·Mounting type: Through hole
·Orientation: Right angle
·Termination: Solder
·Contact resistance: 30mΩ Max.
·Insulation resistance: 100MΩ Min.
·Withstand voltage: 100VAC for 1 minute
·Operating temperature: -40°C to +85°C
·Insertion force: 5N~20N
·Unmating force: 8~20N (initial), 6~20N (after 10000 cycles)
·Durability: 10000 cycles

Materials

·Housing: LCP,UL94-0 black
·Button cover: LCP,UL94-0 black
·Contact: C7025 T=0.12mm; C2680 T=0.15mm
·Socket shell:SUS304-1/2H T=0.3mm
·Front shell:SUS304-1/2H T=0.25mm
·Middle shell:SUS304-1/2H T=0.25mm
·Rear shell:SUS304-1/2H T=0.2mm
·Mid plate:SUS301-1/2H T=0.15mm
