Electrical Characteristics
Features
·The rated current can be offered up to 20 amps.
·Various output selections such as fast-on terminal.
·Low leakage current version upon requested.
·It meets the relevant safety approval regulations.
·Custom-specific versions are available on request.
Specifications
·Current rating: 6A
·Voltage rating: 125VAC / 250VAC
·Operating frequency: 50/60Hz
·Hipot rating (line-to-line): 1450VDC
·Hipot rating (line-to-ground): 1800VAC
·Insulation resistance: 100MΩ Min. at 250VDC
·Leakage current (eachline to ground): 0.8mA Max. 250VAC 50Hz
·Operating temperature: -25°C to +85°C
·Output connections: Fast-on terminal
