Electrical Characteristics
Specifications
·Current rating: 16A
·Voltage rating: 250VAC
·Insulation resistance: 5MΩ Min. at 500VDC
·Dielectric strength: 1500VAC for 1 minute
·Operating temperature: 0°C to 70°C
·Normal operation: 5000 times (10000 strokes)
·Color: White
Materials
·Screw: Steel, Ni plated
·Cover: Polycarbonate (PC), white
·Screw: Steel, brass plated
·Earthing contact: Brass, Ni plated
·Nut: Steel, Ni plated
·Contact tubes: Steel, Ni plated
·Body: Nylon 66
·Earthing holder: Brass
