Features

·Epoxy molded single in line structure.
·Higher mounting density than DIP type.
·Completely washable.
·Miniature cost effective switching solution.
·Is a UL recognised componet (E155181).

Specifications

Electronical:
·Contact form: 1A (Normal open)
·Contact rating:
Max. switching power: 10VA
Max. switching voltage: 100VDC
Max. switching current: 0.5ADC
Max. carry current: 1.0ADC
·Contact resistance: 150mΩ Max.
·Operate time (including bounce time): 1.0ms Max.
·Release time: 0.5ms Max.
·Dielectric strength:
Coil to contact: 1400VDC
Between contacts: 250VDC
·Insulation resistance: 10000000000Ω Min.
·Shock resistance: 30G Min.
·Coil rating:
Contact form: 1A (Normal open)
Nominal voltage: 12VDC
Coil resistance: 1000Ω±10%
Nominal input power: 144mW
Pull in voltage: 9V
Drop out voltage: 1.0V
Operate voltage: 20V Max.
Mechanical and environmental:
·Operating temperature: -40°C to +85°C
·Storage temperature: -55°C to +125°C
·Life expectancy (Ref 10VDC/10mA): 10 x 1000000
·Solderability: After flux 230±5°C for 5±0.5 seconds 95% coverage
