Characteristics
·Motor design: Single phase, 6-poles brushless DC motor
·Insulation resistance: 20MΩ Min. between internal stator and lead wire(+) measured
at 100VDC.
·Dielectric strength: Applied 500VAC for one minute or 600VAC for 2 seconds between
housing and lead wire(+) .
·Noise level: Measured in a semi-anechoic chamber with background noise level below
15dB(A). The fan is running in free air with the microphone at a distance of one
meter from the fan intake.
·Input power, current & speed: Measured after continuous 10 minutes operation at
rated voltage in clean air, and at ambient temperature of 25°C.
·Tolerance: ±15% on rated power and current.

Specifications

·Rated voltage: 3VDC
·Rated current: 37 mA
·Rated power: 0.1 WATTS
·Operating voltage range: 2.0~3.5VDC
·Starting voltage: 2.0VDC (25°C power on/off)
·Rated speed: 12500 RPM ± 30%
·Air delivery: 6.17 l/min
·Static pressure: 40.34 Pa
·Noise level: 22.0 dB(A)@ 1M；32.6 dB(A)@ 0.3M
·Direction of rotation: Counter-clockwise viewed from front of fan blade
·Operating temperature: -10°C to +70°C
·Storage temperature: -40 C°to +70°C
·Bearing system: VAPO bearing system

Materials

·Frame: Thermoplastic LCP A130 of UL94V-0
·Impeller: Thermoplastic LCP A130 of UL94V-0
·Lead wire: UL10064, 32AWG, +red / -black / yellow-3rd wire
