Electrical Characteristics
Specifications
·Gender: Female
·USB connector type: A
·Orientation: Right angle
·Mounting type: Through hole mount
·Termination: Solder
Materials
·Housing: PBT polyester UL94V-0 mixed fiber glass, black
·Contact: 0.35mm Thick phos-bronze plated with 6u" hard gold and gold flash in
solder area
·Shield: 0.2mm Thick copper alloy, nickel plated
·Cavity confirms to FCC rules and regulations part 68, subpart F.
