Electrical Characteristics
Specifications
·Circuit: DPDT
·Switch function: On-Off-On (LED dependent)
·Rating: 16A 125VAC / 16A 250VAC
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 1500VAC for 1 minute
·Operation temperature: -40°C to +85°C
·Water proof and dust proof to fit IP67 (with panel seal)
Materials
·Frame: Nylon 66 (UL94-V2), black
·Actuator: Nylon 66 with 33% glass fiber (UL94-V0), black
·Lens 1: PC (UL94V-2), red
·Lens 2: PC (UL94V-2), green
·LED 1 : Red, Vf=2.2V, If=20mA, 120mcd
·LED 2 : Green, Vf=3.7V, If=20mA, 700mcd
