Electrical Characteristics
Features
·Reverse polarity protection
·LED power indicator inside
·Screw in USB charger with dust-proof cover
·Suitable for most mobile phones, MP3 players and more
Specifications
·Output connector: USB A socket
·Input voltage: 12VDC / 24VDC
·USB output current: 2.4A
·USB output voltage: 5VDC
·Faston terminals: 6.3mm
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 1500VAC for 1 minute
·Operation temperature: 0°C to +60°C
Materials
·Housing: Nylon with glass fiber (UL94-HB)
·Mounting plate: Nylon with glass fiber (UL94-HB)
·Surface mounting case: ABS
·Cap: PVC
