Electrical Characteristics
Specifications
·Temperature: 75°C
·Function: Normally close
·Reset type: Auto reset
·Electrical rating: 15A 125VAC / 10A 250VAC
·Reset differential: 10°C to 20°C
·Tolerance: ±3°C, ±5°C
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min.
·Dielectric strength: 1500VAC for 1 minute
·Life cycles: 100,000 cycles under rated load
Applications
·Espressor machines
·Vending machines
·Toaster, Microwave
·Photo copier, UPS
·Roomheater
·Home & heating appliances
