Features

·Ultra-thin and flexible, with better performance at high temperature, humidity and repeatability.

Specifications

·Active area: Φ14.7mm
·Force sensitivity range: 30g~1000g (0.3N~9.8N)
·Force resolution: Continuous (analog)
·Stand-off resistance: >20MΩ (unloaded)
·Force repeatability (single part): 2%
·Force repeatability (part to part) : 5%
·Response time: <1ms
·Hysteresis: 10%
·Long term drift: <10% log10 (time)
·Operating temperature: -30°C to +85°C
·Life cycle (without failure): >10 million
·High humidity storage: +70°C, 85%RH x 96hrs
·High temperature storage: +85°C x 120hrs
·Low temperature storage: -30°C x120hrs
Application
·Fitness, medical, industrial and many other applications
