電器特性
Specifications
·Pitch: 3.5mm
·No. of contacts: 4
·Current rating: 2A
·Voltage rating: 300VAC
·Withstanding voltage: 1.6KV
·Wire range: 2 x AWG 20-26 (solid wire)
·Operating temperature: -40°C to +115°C
·Stripping length: 5-6mm
·Color: Black, red, orange, yellow, green, blue, grey, white, multiple colors
Materials
·Insulating body (middle): Thermosplastic, UL94V-0
·Insulating lever: Thermoplastic, UL64V-0, orange (RAL2011/P)
·Spring clamp: Phosphor bronze, tin plated
·Insulating cover: Thermoplastic, UL94V-0
·Insulating body (side): Thermoplastic, UL94V-0
