電器特性
Specifications
·Type: Board to board
.Gender: Female
·Pitch: 1.0mm
·No. of contacts: 20
·Current rating: 0.5A
·Orientation: Vertical
·Mounting type: Surface mount
·Mounting style: SMD/SMT
·Termination: Solder
·Insulation resistance: 100MΩ Min. at 100VDC
·Withstand voltage: 500VAC for 1 minute
·Operating temperature: -40°C to +85°C
Materials
·Housing: LCP, UL94V-0, black
·Contact: Phosphor copper
