Electrical Characteristics
Specifications
·Circuit: SPST
·Switch function: On-Off
·Rating: 10A 125VAC / 6A 250VAC
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 1500VAC for 1 minute
·Operating temperature: -25°C to +85°C
·Water proof and dust proof to fit IP66
Materials
·Frame: Nylon 66, black
·Actuator: PC, red
·Terminals: Copper alloy, silver plated
·Waterproof rubber: Black, silicone
