Electrical Characteristics
Specifications
·Pitch: 5.0mm
·No. of contacts: 3
·Rated: 11A 250VAC
·Insulation resistance: 1000MΩ Min. at 500VDC
·Withstand voltage: 2000VAC for 1 minute
·Operating temperature: -55°C to +110°C
Materials
·Housing: Polyamide 66 (UL94V-0), green
·Lever: Polyamid 66 (UL94V-0), white
·Terminals: Brass, tin plated
