Electrical Characteristics
Specifications
·Gender: Female
·Mounting type: Surface mount
·USB connector type: AB
·Orientation: Right angle
·Current rating: 1,5 pin 1.8A Max. / 2,3,4 pin 1A Max.
·Contact resistance: 30mΩ Max.
·Insulation resistance: 100MΩ Min.
·Withstand voltage: 100VAC for 1 minute
·Operating temperature: -30°C to +80°C
·Total mating force: 3.57 Kgf Max.
·Total unmating force: 1.0 Kgf Min.
Materials
·Housing: High temperature thermoplastic with G.F., UL94V-0
·Contact: Copper alloy, t=0.2mm
·Shell: Copper alloy, t=0.25mm
