Electrical Characteristics
Features
·Smartphone connectability
·Smart display & USB quick charge 3.0
·Settings fully adjustable by App
·Microcontroller integrated
·Energy saving mode & intelligent fan control
·Input & output fully isolation
·Intelligent PWM output regulation
·Multi pre-alarm & shutdown alarm protections: Battery type detection / polarity reverse / low voltage / short circuit / overheat / overload
·Aluminum housing
·100% Made in Taiwan
Specifications
·Inverter directionality: DC to AC
·Input voltage: 10~15V
·Continuous power: 1500W
·Surge power: 3000W
·Output voltatge: 110/120/127VAC; 220/230/240VAC
·Output waveform: Pure sine wave
·Total harmonic distortion: <3%
·Output USB port: QC3.0 x 2
·Standby current (normal mode): <1.2A
·Standby current (saving mode): <0.15A
·Output regulation: < ±5% Intelligent PWM
·Output frequency: 50/60 Hz
·Efficiency: >85%
·Protection:
Input type auto-detection: Yes
Input polarity reverse protection: Fuse
Input low voltage protection: <10.5V Pre-alarm, <10V Shutdown & alarm
Output short circuit protection: Yes
Output overheat protection: > 70°C ~ 90°C Pre-alarm, > 75°C ~ 95°C Shutdown & alarm
Output overload protection: > 80% ~ 110% Pre-alarm, > 90% ~ 120% Shutdown & alarm
Cooling: Intelligent fan
·Fuse: 25A x 8PCS
·AC outlets: 2
·Dimension (LxWxH): 430 x 227 x 88 mm
·Net weight: 5.3 KGs
·RC (standard0 accessory: Yes
