Electrical Characteristics
Features
·Digitized programmable interface
·High resolution
·High stability, low drift
·Over-voltage, over-current, over temperature protection
·Intelligent fan control (changes by output power)
·Built-in buzzer alarm
·Labview driver
Specifications
·Power source: 100V/120V/220VAC±10%, 230VAC(+10%~-6%), 50/60Hz
·No. of outputs: 1 Output
·Power rating: 96W Max.
·Output voltage: 0 - 32V
·Output current: 0 - 3A
·OVP: 0 - 33V
·Setting resolution: 10mV/1mA
·Standard interface: RS-232C
·Response time
Voltage up 10%~90%: ≦100mS
Voltage down 90%~10%: ≦100mS (≧10% rating load)
·Dimension: 315 (D) x 108 (W) x 140 (H) mm
·Weight: Approx. 4.8KGS
