Features

·0.025ppm Frequency stability and 1ppm aging Rate
·Built-in preamplifier, 50dB Attenuator, and Sequence Function
·Built-in AM/FM Demodulation & Analysis
·Built-in spectrogram, topographic and dual-view display modes
·Remote control interface: LAN, USB, RS-232

Specifications

·Power source: 100V ~ 240VAC, 50/60Hz
·Sweep time range: 204us ~ 1000s
·Frequency Range: 9kHz ~ 3 GHz
·RBW: 1Hz ~ 1MHz
·Sensitivity: -149dBm/Hz (@PreAmp on)
·Measurement range (preamp on)
-108dBm~+18dBm: 100kHz~1MHz, Ref.Lv.@-60dBm
-142dBm~+21dBm: 1MHz~10MHz, Ref.Lv.@-60dBm
-142dBm~+30dBm: 10MHz~3GHz, Ref.Lv.@-60dBm
(Span = 500Hz, RBW = 10Hz)
·Display device: 800 x 600 high resolution TFT color LCD
·Power measurement: ACPR, OCBW, channel power and N-dB bandwidth
·Level display modes: Trace, Topographic, Spectrogram, Single/split windows
·Trace functions: Clear & Write, Max/Min Hold, View, Blank, Average
·Phase noise
<-88dBc/Hz: 10kHz
<-95dBc/Hz: 100kHz
<-113dBc/Hz: 1MHz
Offset from carrier: Fc=1GHz;RBW=1kHz,VBW=10Hz
·Interface
RF input: N female connector, 50Ω nominal
SMB male: 7VDC/500mA Max.
RS232: D-Sub 9pins female connector
USB/A plug, MicroSD socket(SD1.1)
·Dimension: 100 (D) x 350 (W) x 210 (H) mm
·Weight: 4.5KGs
