Specifications

·Gender: Female
·USB connector type: C
·Current rating: 5A
·Voltage rating: 5V
·No. of positions: 14 Ways
·Mounting type: Through hole
·Orientation: Right angle
·Termination: Solder
·Insulation resistance: 100MΩ Min.
·Withstand voltage: 100VAC for 1 minute
·Operating temperature: -25°C to +85°C
·Insertion force: 0.5~2.0kgf
·Extraction force: 0.8kgf~2.0kgf
·Durability: 10000 cycles

Materials

·Housing: PA9T, UL94V-0, black
·Contact: Copper alloy, Au/Ni plated
·MID plate: Stainless steel
·EMI plate: Stainless steel
·Shell: Stainless steel, nickel plated
