電器特性
Specifications
·Gender: Female
·Signal lines: Mono
·Body orientation: Right angle
·Mounting: Through hole
·Termination: Solder
·Insulation color: Red, black
.Contact resistance: 30mΩ Max.
.Insulation resistance: 100MΩ Min. at 500VDC
.Withstanding voltage: 500VAC for 1 minute
Materials
.Earth terminal: Brass 0.4t, nickl plated
.Pin : Brass 0.6t, silver plated
.Metal shell: Iron 0.4t, nickel plated
.Housing: PBT, black
