Overview
MMCX Connector – Micro RF Connector with 360° Rotation
MMCX connectors are micro-size RF coaxial connectors with snap-on coupling and full rotational flexibility. Common in wearables, wireless devices, and antennas, they operate up to 6 GHz for compact, portable applications.
Specifications
·Gender: Male - female
·Adapter type: MMCX to SMA
·Adapter type A: MMCX
·Adapter type B: SMA
·Impedance: 50Ω
·Body orientation: Straight
·Contact resistance: 3.0mΩ Max.
Materials
·Body: Brass, gold plated
·Pin: Phosphor bronze, gold plated
·Insulator: Teflon
·C ring: Beryllium copper, gold plated
