Electrical Characteristics
Features
·Snap in type with ground pin
·Guide bosses available
·Cap options
Specifications
·Rating: 50mA 12VDC
·Contact resistance: 100mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 250VAC for 1 minute
·Operation force: 160±50gf
·Stroke : 0.35mm
·Operation temperature: -25°C to +70°C
·Storage temperature: -30°C to +80°C
·Electrical life: 200,000 cycles
Applications
·Audio
·OA equipment
·Instrumentation
·Industrial
