Electrical Characteristics
Features
·Sealed
·Reflow solderable
·Dust proof with high reliability
Specifications
·Current rating: 50mA
·Voltage rating: 12VDC
·Travel: 0.25mm
·Mounting type: Surface mount
·Illumination: Non-illuminated
·Contact resistance: 100mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 250VAC for 1 minute
·Operation force: 160±50gf
·Operation temperature: -25°C to +70°C
·Storage temperature: -30°C to +80°C
·Protective grade: IP67
·Electrical life: 100,000 cycles Min.
Applications
·Audio
·OA equipment
·Instrumentation
·Communication
·White goods
