Electrical Characteristics
Overview
Fuse Holder – Secure Fuse Mounting
Fuse holders mount and protect electrical fuses for safe circuit protection. Available in panel, PCB, and in-line types, they provide insulation, easy replacement, and reliability in power and electronics applications.
Specifications
·Current rating: 15A
·Fuse type: Blade
·Orientation: Vertical
·Mounting: Through hole
·Termination: PC pin
·Storage temperature: 25°C(+5°C, -10°C)
·Insertion & extraction: 1 Kgf Min.
·Type: Ear type
Materials
·Metal: Spring brass
·Thickness: 0.35 ± 0.03mm
·Finish : Bright tin plated
