Electrical Characteristics
Specifications
·Gender: Male
·No. of contacts: 13
·Orientation: Straight
·Rating: 1A 100VAC / 1A 12VDC
·Contact resistance: 20mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 250VAC for 1 minute
·Mounting type: Cable mount
·Contact termination: Solder
·Insertion force: 4.0KGS Max.
·Withdrawal force: 1-3.5KGS
·Operation temperature: -20°C to +85°C
·Life: 1000 cycles Min. after testing
Materials
·Boot: EVA
·Metal part: Steel, nickel plated
·Insulator: PBT
·Pin contact: Brass, silver plated
