Electrical Characteristics
Specifications
·Gender: Female
·No. of contacts: 5
·Rating: 1A 100V AC
·Orientation: Straight
·Contact resistance: Pins-30mΩ Max. / shell-50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Withstand voltage: 250VAC R.M.S. for 1 minute
·Mounting type: Cable mount
·Contact termination: Solder
Materials
·Shell cover: EVA+LLDPE, black
·Shield cover A & B: Steel, nickel plated
·Housing: ABS
·Contact terminals: Brass, silver plated
