Electrical Characteristics
Specifications
·Gender: Female - female
·Adapter type: SMA to BNC
·Adapter type A: SMA
·Adapter type B: BNC
·Impedance: 50Ω
·Body orientation: Straight
·Voltage rating: 500VAC
·Contact resistance: 3.0mΩ Max.
·Insulation resistance: 5000MΩ Min. at 500VDC
Materials
·Body: Brass, nickel plated
·Pin: Brass, gold plated
·Insulator: Teflon
