Electrical Characteristics
Specifications
·Gender: Female - female
·Adapter type: F to F
·Adapter type A: F female
·Adapter type B: F female
.Impedance: 75Ω
·Body orientation: Straight
·Mounting type: Panel mount
.Frequency range: 0-2GHz
.Voltage rating: 250VAC
·Contact resistance: 5.0mΩ Max.
·Insulation resistance: 1000MΩ Min. at 500VDC
·Withstand voltage: 500VAC for 1 minute
Materials
·Body: Zinc, nickel plated
·Insulator: Delrin
·Washer : Zinc, nickel plated
·Nut: Brass, nickel plated
