Electrical Characteristics
Specifications
·Pitch: 1.27mm
·No. of rows: 1
·No. of contacts: 30
·Current rating: 1A Max.
·Mounting type: Through hole
·Orientation: Straight
·Termination: Solder
·Insulation resistance: 1000MΩ Min. at 500VDC
·Withstand voltage: 600VAC RMS for 1 minute
·Operating temperature: -55°C to +105°C
Materials
·Housing: Thermoplastic (UL94V-0), black
·Terminal: Sq. 0.4mm copper alloy, gold plated
