Electrical Characteristics
Specifications
·Pitch: 2.54mm
·Gender: Male
·No. of contacts: 12
·Current rating: 5A
·Voltage rating: 150VAC
·Insulation resistance: ≧500MΩ at DC 500V
·Connection method: Push-in design
·Type of locking: Without
·Level: Double level
·Operating temperature: -40°C to +120°C
·Stripping length: 7-8mm
·Color: Black
Materials
·Insulation: PA, flame retardant rating UL94V-0
·Conductor: Copper alloy, tin plated
