Electrical Characteristics
Specifications
·Circuit: SPDT
·Switch fucntion: On-On
·Rating: 3A 125VAC / 3A 250VAC
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Withstand voltage: 1000VAC for 1 minute
·Operating force: 115±30gf
·Operating temperature: -25°C to +80°C
·Soldering temperature: 245±5°C for 3 seconds
·Ambient humidity used: 85% RH Max.
·Mechanical life: 100,000 cycles
·Electrical life: 6,000 cycles
Materials
·Upper housing: PBT
·Lower housing: PBT
·Button: PBT
·Spring: SUS304
·Terminals: C2680
·Contact: Silver alloy
·Change plate: C5210
