Panel mount IEC connector AC socket
Without fuse terminal 4.8mm
With approvals
250V 10A
  • Item No.:K241334
  • Product Range : AC Socket
  • Approval:
Unit price (USD)
Quantity Price
25+ 3.2051
30+ 2.6709
Add
Enter Quantity to Check Lead Time
Data Sheet
Electrical Characteristics

Overview

AC Socket – Reliable Power Inlet
AC sockets provide safe, stable power input to devices. Common in computers, appliances, and industrial equipment, they are available in IEC C13, C14, and custom configurations for secure connections.

Specifications

·Gender: Male
·Current rating: 10A
·Voltage rating: 250VAC
·Mounting: Panel mount
·Body orientation: Straight
·Termination: Quick connect
·Faston terminals: 4.8 x 0.8mm
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 2000VAC for 1 minute
·Operating temperature: -25°C to +85°C

Materials

·Body: Nylon#66, UL94V-2
·Fuse cover: Nylon#66, UL94V-2
·Edge terminal: Bsp1-1/2H, t=2.0, Ni plated
·Center terminal: Bsp1-1/2H, t=2.0, Ni plated
·Connection terminal: Bsp1-1/2H, t=0.8, Sn plated
·Fuse holder: Bsp1-1/2H, t=0.5, Sn plated
·Fuse holder: Bsp1-1/2H, t=0.8, Sn plated
·Connector: Bsp1-1/2H, t=0.6, Ni plated
·Connector: Bsp1-1/2H, t=0.4, Cu
