Electrical Characteristics
Specifications
·Gender: Female
·No. of contacts: 5
·Rating: 1A 100V AC / 2A 12V DC
·Orientation: Straight
·Contact resistance: 30mΩ Max. (initial)
·Insulation resistance: 50MΩ Min. at 250VDC
·Withstand voltage: 500VAC for 1 minute
·Mounting type: Cable mount
·Contact termination: Solder
Materials
·Boot: EVA
·Metal part: Steel, nickel plated
·Insulator: PC
·Pin contact: Brass, silver plated
