Solderless breadboard round hole
108 tie points W/O jumper wire
Tray packing
Price per each (USD)
Quantity Price
28+ 4.5406
Add
Enter Quantity to Check Lead Time
Data Sheet
Electrical Characteristics

Features

·Durable Al nameplate stands static interference
·Using phosphor bronze / nickel o get lasting endurance of insertion hole
·High - class acetal ABS material of plastic
·Spring clip with solder tail
·ldeal for sophisticated digital training and test system
·Can insert to board which has built-in circuit and be connected

Specifications

·Tie points: 108
·Hole type: Round
·Insertion range: 0.4-0.7mm
·Contact life: 50,000 times
·Heat distortion temperature : 84°C

Materials

·Plastic: ABS
·Surface: White
·Spring clip contact: Phosphor bronze, nickel plated
·Packing: Tray packing
Accessories
·Board: 76.2 x 16.0 x 8.4mm
