Features

·Conformity in surfact design with SAE J1772, as well as product test accordance with UL2251.
·Ergonomic and streamlined designs allow for user-friendly interatcion.
·High level of protection against severe environment.
·Products passed 5000N driveover test.
·Applicable to connection B and connection C of IEC61851.
Application
·BEV, PHEV, charging pile, cord set and domestic wall-mounted charger, etc.

Specifications

·Voltage rating: 240VAC
·Current rating: 40A
·Cable length: 5M
·Lifespan: ≧10000 times
·Flammability rating: UL94V-0
·Protection level: NEMA 4 (Body IP67)
·Operating temperature: -30°C to +50°C
·Cable specification: 2x8AWG+1x10AWG+1x18AWG
·Plug color: Black
·Main materials: PBT / PC / PA66 / Copper alloy
