Electrical Characteristics
Specifications
·Rating: 50mA 12VDC
·Contact resistance: 100mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Withstanding voltage: 250VAC for 1 minute
·Operating force: 1st=100±50gf, 2nd=260±80gf
·Operating temperature: -20°C to +70°C
·Soldering temperature: 300±5°C Max. for 3 seconds
Materials
·Cover: Bronze phosphor, Ag plated
·Terminal: Bronze phosphor, Ag plated
·Body: PA9T
·Dome: Stainless steel, Au plated
·Dust-proof sheet: PA9T
