Electrical Characteristics
Specifications
·No. of contacts: 25
·IP rating: IP67
·For use with: D-sub connectors
·Temperature range: -40°C to +90°C
·Color: Black
·Length: 68.8 mm
Materials
·Sealing nut: PA66
·Seal: Silicone
·Clamp ring: PA66
·Screw: FE, nickel plated 100u"
·O-ring 1: Silicone
·O-ring 2: Silicone
·Housing: PC+ABS
·Gasket: Silicone
