Electrical Characteristics
Specifications
1.Electrical
·Contact rating: 25mA 24VDC (switching) ; 100mA 50VDC (non-switching)
·Contact resistance: 50mΩ Max.
·Insulation resistance: 100MΩ Min. at 500VDC
·Dielectric strength: 500VDC Min. for 1 minute
·Capacitance between adjacent switches 5pF Max.
2.Mechanical
·Operating temperature: -20°C to + 85°C
·Storage temperature: -40°C to + 85°C
·Operation force: 1000gf Max.
·Mechanical life: 2000 operations
·Humidity: 95﹪RH, 40°C for 96 Hrs.
·Vibration: Per MIL-STD-202F, method 201A
